RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 05
PAGE 30
PAGE DATE: 1. July 1996
Engine compartment
O 1 Check firewall for dents, cracks and deformation.Visual inspection of
PR 812 sealant for porosity and general condition.
O 2 Inspect tubular engine mount for dents, cracks and corrosion. Check
all bolts for security and condition.
O 3 Visual inspection of rubber mounts (shock mounts) for porosity and
general condition.
O 4 Inspect flexible hoses for damage and leakage.
O 5 Visual inspection of fire sleeves for chaffing and general condition.
O 6 Check electric wiring for proper connection.
O 7 Check grounding straps for proper connection.
O 8 Visual inspection of inverted oil system for general condition accord-
ing to CHRISTEN 801instruction. Refer to CHRISTEN Product
Manual P/N: 70047-001 or to TEXTRON LYCOMING Operator`s
Manual P/N: 60297-21.
O 9 Carry out general engine check as instructed by TEXTRON
LYCOMING Operator`s Manual P/N: 60297-21.
O 10 Visual inspection of cowling for dents,cracks,delamination and smoke
marks.
Hardware
O 1 Magnaflux or fluorescent dye-check of the wing main spar bolts by
authorized personnel is required. (Remove only one bolt at a time).
Inspect for security of the spar bolts and safety-screws.
O 2 Check harness attachment fittings for cracks, deformations and
corrosion.
O 3 Check bolts and nuts in critical areas for fretting, wear, damage,
stretch, proper torque and safety.
O 4 Visual inspection of center tank fastening straps for cracks, damage
and corrosion.
O 5 Visual inspection of battery fastening straps for cracks, damage and
corrosion.
O 6 Check the "quick pins" of the seat adjustment for cracks, deforma-
tions and corrosion. Inspect wear and proper function.
Inspector:
Mechanic:
Inspections
Date:
Serial No.:
1000 hours
SCHEDULED MAINTENANCE CHECKS
Significant Items Inspection
