EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 05
PAGE 29
PAGE DATE: 1. July 1996
Inspector:
Mechanic:
Inspections
Date:
Serial No.:
1000 hours
O 5 Check rod end bearings for free movement and cleanliness.
O 6 Detailed visual of trim actuator lever for damages and cracks. Ensure
proper attachment and condition of friction.
Main landing gear
O 1 Inspect landing gear spring visually for dents, cracks and delaminations,
especally at the axle attachment and the center bushing for wear and
looseness.
O 2 Check mounting clamp for damage and corrosion. Inspect for dents
and cracks.
O 3 Inspect mounting clamp bolts and nuts for fretting, wear, damage,
stretch and proper torque (refer to Chapter 20-10-03).
O 4 Check brakes discs for warping and wear. Inspect wheel brake
cylinder mounting bracket for wear.
O 5 Inspect brake lines for leakage, dents, cracks, chaffing, kinks and
security of anchorage.
O 6 Inspect axle attachment bolts and nuts for fretting, wear, damage, and
stretch.
O 7 Check tires for general condition.
Tail-wheel landing gear
O 1 Inspect glass fibre spring visually for dents, cracks and delaminations.
O 2 Inspect mounting bolts and nuts for fretting, wear, damage, stretch
and proper torque.
Steerable tail-wheel
O 1 Disassemble tail wheel per Ch. 32. Inspect for signs of wear and
damage. Check general condition and proper function.
O 2 Check connector springs for signs of wear and light precompression.
Pay attention to the free movement of the rudder.
O 3 Inspect wheelfork visually for damage, dents, cracks and corrosion.
O 4 Inspect axle bolt and nut for fretting, wear, damage, and stretch.
O 5 Check rubber tire for general condition.
SCHEDULED MAINTENANCE CHECKS
Significant Items Inspection
