25
ASSEMBLY AND INSTALLATION INSTRUCTIONS
Chapter5
CHIMNEY CAPS, DISTANCES AND POSITIONING
Roof
inclination
Distance between the
ridge and the chimney
Minimum chimney height
(measured from outlet)
β A (m) H (m)
15°
< 1,85 0,50 m over the ridge
> 1,85 1,00 m from roof
30°
< 1,50 0,50 m over the ridge
> 1,50 1,30 m from roof
45°
< 1,30 0,50 m over the ridge
> 1,30 2,00 m from roof
60°
< 1,20 0,50 m over the ridge
> 1,20 2,60 m from roof
CONNECTION TO EXTERNAL AIR INLETS
The appliance must be able to use the necessary air to guarantee regular functioning through external air
inlet. The air inlets must comply with the following requisites:
have a total free section of at least 80 cm.1.
must be protected by grates, metal net or suitable protections as long as they do not reduce the minimum 2.
section stated in point 1 and positioned in order to avoid them being obstructed.
If the combustion agent air is withdrawn directly from outside through a pipe, a downward bend must
be mounted outside or a protection against the wind and no grids or similar must be positioned. (it is
recommended that the air vent always communicates directly with the installation room even if the air is
withdrawn from outside through a pipe). The air ow can also be obtained from an adjacent room to the
installation one, as long as the ow can happen freely through permanent openings communicating with
the outside.
The adjacent room, respect to the installation one, must not be put in depression respect to the external
environment by means of reverse draught caused by the presence of another used appliance or intake
device in such room. The permanent openings in the adjacent room must comply with the above-described
requisites. The adjacent room cannot be set up as garage, storage for fuelling material or activity with
danger of re.
INSULATION, FINISHINGS, COVERING AND SAFETY RECOMMENDATIONS
The coverings, independently from the materials with which they are made, must constitute a self-
supporting construction respect to the heating block and not be in contact with it.
The wooden or fuelling materials beam and nishings must be positioned outside the hearth radiation
area or adequately insulated.
In case coverings in fuelling material or sensible to heat exist in the space above the generator, an insulating
and non fuelling protection diaphragm must be inserted.
Elements in fuelling or in ammable material like wooden furniture, curtains, etc., directly exposed to the
hearth radiation, must be positioned at a safe distance. The appliance installation must guarantee easy
access for cleaning the same appliance, discharge gas pipe and ue.
NATIONAL, REGIONAL, PROVINCIAL AND TOWN COUNCIL REGULATIONS
It is necessary to bear in mind all laws and national, regional, provincial and town council Standards present
in the country the appliance has been installed.
