Installation Guide 11
The AP-7522’s supported Power Injector (Part No. AP-PSBIAS-2P3-ATR) is a high power
POE Injector delivering up to 30 watts. The Access Point can only use a Power Injector when
connecting the unit to the Access Point’s GE1/POE port. The Power Injector is separately
ordered and not shipped with an existing AP SKU.
The Access Point Power Supply (Part No. PWRS-14000-54R) is not included with the Access
Point and is orderable separately as an accessory. If the Access Point is provided both POE
power and PWRS-14000-54R power concurrently, the Access Point will source power from the
PWRS-14000-54R supply only. Disconnecting the AC power from the PWRS-14000-54R
causes the Access Point to re-boot before sourcing power from the POE power injector. If the
AP is operating using injector supplied power, the AP will not automatically reboot if an AC
adapter is connected. The Access Point continues to operate with power supplied from the AC
adapter without change to the Access Point operating configuration. If using AC adapter
supplied power and a change to the AP’s operating configuration is warranted, the Access
Point needs to be manually rebooted by the customer.
CAUTION Do not plug the AP-PSBIAS-2P3-ATR Power Injector into
the Access Point’s Console port. Connecting the Power
Injector into the console port can damage the port and
void the AP-7522’s product warranty.
CAUTION The Access Point supports any standards-based
compliant power source. However, using the wrong
solution (including a POE system used on an Access
Point) could either limit functionality or severely damage
the Access Point and void the product warranty.
