Installation Guide 7
1.5 AP-7522 Antennas
1.5.1 AP-7522 Dual Band 2.4 GHz / 5 GHz Antennas - US
An AP-7522 external antenna Access Point supports the following dual band antenna options
for the US:
*
* This antenna is for indoor placement only.
1.5.2 AP-7522 Dual Band 2.4 GHz / 5 GHz Antennas - EU
*An external antenna AP-7522 supports the following dual band antenna options for the EU:
NOTE Per FCC requirement, the use of the Access Point on
UNII-1 of 5GHz band requires installers to input antenna
elevation gain during configuration if the AP placement is for
outdoor coverage. This information can be found in Zebra
antenna guide located at www.zebra.com/support
.
Part Number Antenna Type
2.4 GHZ Gain
(dBi)
5 GHZ Gain
(dBi)
Elevation Gain
for outdoor
placement (dBi
)
ML-2452-APA2-01 Dipole 3.17 4.85 na*
ML-2452-HPA5-036 Dipole 3 5 -2.56
ML-2452-APAG2A1-01 Dipole 2.7 1.7 na*
ML-2452-HPAG4A6-01 Dipole 4 7.3 5.7
ML-2452-HPA6-01 Dipole 5.3 6.1 4.09
ML-2452-PNL9M3-N36 Polarized-Panel 11 10.7 7.3
ML-2452-PNA5-01R Panel 5.5 6 5.2
ML-2452-PTA3M3-036 Patch 5 4 na*
ML-2452-VMM5M3-N72 Patch 4.5 5.4 2.9
Part Number Antenna Type 2.4 GHZ Gain (dBi) 5 GHZ Gain (dBi)
ML-2452-APA2-01 Dipole 3.17 4.85
ML-2452-HPA5-036 Dipole 3 5
ML-2452-APAG2A1-01 Dipole 2.7 1.7
ML-2452-HPAG4A6-01 Dipole 4 7.3
ML-2452-HPA6-01 Dipole 5.3 6.1
