Installation Guide 9
2 Hardware Installation
2.1 Installation Instructions
An AP-7522 Access Point mounts either on a wall (with M 3.5 x 0.6 x 23 MM pan head screws
and mounting bracket- or equivalent) or on a suspended ceiling T-bar.
To prepare for the installation:
1. Match the part number on the purchase order with the part numbers in the packing list
and on the case of the Access Point.
2. Verify the contents of the box include the intended AP-7522 Access Point, and the
included hardware matches the package contents
(see
AP-7522 Package Contents on page 6).
3. Review site survey and network analysis reports to determine the location and
mounting position for the AP-7522 Access Point.
4. Connect a CAT-5 or better Ethernet cable to a compatible 802.3at or 802.3af power
source and run the cable to the installation site. Ensure there is sufficient slack on the
cable to perform the installation steps.
Part Number Description
AP-7522-67040-US
AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point external antenna
US version
AP-7522-67040-WR
AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point external antenna
International version
AP-7522-67040-EU
AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point external antenna
EU version
AP-7522-67030-US
AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point internal antenna
US version
AP-7522-67030-WR
AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point internal antenna
International version
AP-7522-67030-EU
AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point internal antenna
EU version
NOTE
When operating in a Gigabit Ethernet environment, CAT-5e
or CAT-6 cable is recommended for Gigabit operation.
