1.5.3 AP-7522 Internal Antenna Model
An AP-7522 internal antenna Access Point supports the following dual band antenna:
1.5.4 AP-7522 Dual Band 2.4 GHz / 5 GHz Antennas - Canada
*An external antenna AP-7522 supports the following dual band antenna options for Canada: :
ML-2452-PNL6M3-N36 Polarized-Panel 6 6
ML-2452-PNA5-01R Panel 5.5 6
ML-2452-PTA3M3-036 Patch 5 4
ML-2452-VMM5M3-N72 Patch 4.5 5.4
Antenna Type 2.4 GHZ Gain (dBi) 5 GHZ Gain (dBi)
PIFA 4.13 5.92
Part Number Antenna Type 2.4 GHZ Gain (dBi) 5 GHZ Gain (dBi)
ML-2452-APA2-01 Dipole 3.17 4.85
ML-2452-HPA5-036 Dipole 3 5
ML-2452-APAG2A1-01 Dipole 2.7 1.7
ML-2452-HPAG4A6-01 Dipole 4 7.3
ML-2452-HPA6-01 Dipole 5.3 6.1
ML-2452-PNL9M3-N36 Polarized-Panel 11 10.7
ML-2452-PNA5-01R Panel 5.5 6
ML-2452-PTA3M3-036 Patch 5 4
ML-2452-VMM5M3 -N72 Patch 4.5 5.4
NOTE
A professional installer must enter the antenna type, gain,
and indoor/outdoor placement using the CLI. The AP
software uses this information and hardcode maximum
limits determined during testing to limit the EIRP. Please
note, the maximum EIRP in band 5.25-5.35GHz is limited to
23dBm. This limit is hardcoded in the software for this band.
Part Number Antenna Type 2.4 GHZ Gain (dBi) 5 GHZ Gain (dBi)

Extreme Networks AP-7522 Specifications

General

Brand	Extreme Networks
Model	AP-7522
Category	Wireless Access Point
Language	English
