AVT 200HD Tuner • Reference Information 9696
Scaled resolution ............................ 480i
1
, 480p
1
, 720p
2
, 1080i
2
1
= at 59.94 Hz,
2
= at 60 Hz
DC offset ....................................... ±50 mV with input at 0 offset
Video output — digital
Number/signal type ........................ 1 single link HDMI with audio
Connector ...................................... 1 female HDMI type A
Scaled resolution ............................ 480p
1
, 720p
2
, 1080i
2
1
= at 59.94 Hz,
2
= at 60 Hz
Sync
Output type ................................... RGBHV, bi-level and tri-level for component video
Output level ................................... 2.75 V to 5.0 Vp-p for RGBHV
0.6 Vp-p for component video tri-level sync
0.3 Vp-p for component video bi-level sync
Output impedance ......................... 75 ohms
Polarity ........................................... Negative (default) or positive, selectable
Audio output — analog
Number/signal type ........................ 1 balanced/unbalanced stereo
1 unbalanced stereo
Connectors .................................... (1) 3.5 mm captive screw connector, 5 pole
1 pair of female RCA jacks
Impedance ..................................... 50 ohms unbalanced, 100 ohms balanced
Frequency response ........................ 20 Hz to 20 kHz, ±0.5 dB
Gain error ...................................... ± 0.5 dB channel to channel
Nominal level ................................. -10 dBV (316 mVrms), +4 dBu (1.23 Vrms)
Maximum level (Hi-Z) ...................... +10 dBV (unbalanced), +18 dBu (balanced)
Audio output — digital
Number/signal type ........................ 2 S/PDIF (1 optical, 1 coaxial)
Formats .......................................... PCM, AC-3 (Dolby Digital 5.1)
Connectors .................................... 1 TOSLINK
™
fiber optic connector
1 RCA jack
Control/remote — tuner
NOTE: The front panel USB port and rear panel RS-232 port are independent of each other and can be used at the
same time.
Serial control port ........................... 1 bidirectional RS-232, 3.5 mm captive screw connector, 5 pole (shared with
wired IR control)
Baud rate and protocol ................... 115200, 38400, 19200, or 9600 baud (default); 8 data bits; 1 stop bit; no parity
Serial control pin configurations ..... 1 = Tx, 2 = Rx, 3 = GND, 4 = modulated IR, 5 = +12 VDC
USB control ports ........................... 1 front panel female mini USB B
USB standards ................................ USB 2.0, low speed
Ethernet control port ...................... 1 RJ-45 female
Ethernet data rate .......................... 10/100Base-T, half/full duplex with autodetect
Ethernet protocol ........................... ARP, ICMP (ping), IP, TCP, DHCP, HTTP, SMTP, Telnet
Ethernet default settings ................ Link speed and duplex level = autodetected
IP address = 192.168.254.254
Subnet mask = 255.255.0.0
Default gateway = 0.0.0.0
DHCP = off
Web server ..................................... Up to 200 simultaneous sessions
7.25 MB nonvolatile user memory
