AVT 200HD Tuner • Remote Configuration and Control 61
Command
ASCII Command
(Host to Tuner)
Response
(Tuner to Host)
Additional Description
IP Setup Commands (continued)
Set DHCP on
24
E
1DH
}
Idh1
]
Set Dynamic Host Conguration
Protocol (DHCP) to On. The
AVT automatically obtains
its IP address from the local
network.
Set DHCP off
24
E
0DH
}
Idh0
]
Set DHCP to Off.
View DHCP mode
E
DH
} X4%]
For
X4%
:
1 = DHCP is on.
0 = DHCP is off.
Set IP address
EX5$
CI
}
Ipi
X5$] X5$
= IP address
(nnn.nnn.nnn.nnn). Leading
zeros in the octets are optional.
View IP address
E
CI
} X5$]
Leading zeros are suppressed in
returned values.
View hardware (MAC) address
E
CH
} X5(]
In verbose mode:
Iph•
X5(]
X5(
= hardware media
access code (MAC) address
(xx-xx-xx-xx-xx-xx).
View number of open
connections
E
CC
}
Number of connections
In verbose mode:
Icc Number of connections
]
Set subnet mask
EX6)
CS
}
Ips
X6)] X6)
= subnet mask
(nnn.nnn.nnn.nnn). Syntax
is the same as for IP addresses.
Leading zeros are optional in the
octets.
View subnet mask
E
CS
} X6)]
Leading zeros are suppressed in
returned values.
Set gateway IP address
EX5$
CG
}
Ipg
X5$] X5$
= IP address
(nnn.nnn.nnn.nnn). Leading
zeros are optional.
View gateway IP address
E
CG
} X5$]
Leading zeros are suppressed in
returned values.
Set DNS server IP address
EX5$
DI
}
Ipd•
X5$]
Set the IP address
X5$
for the Domain Name
System (DNS) in the format
(nnn.nnn.nnn.nnn). Leading
zeros in the octets are optional.
View DNS server IP address
E
DI
} X5$]
Leading zeros are not shown
response.
Set verbose mode
EX6@
CV
}
Vrb
X6@]
Enable or disable verbose mode
type
X6@
. For
X6@
:
0 = clear/none
1 = verbose mode
2 = tagged responses for queries
3 = mode and tagged responses
for queries.
Default is 0 for Telnet
connections and 1 for RS-232
control.
View verbose mode
E
CV
} X6@]
Set broadcast mode
EX9%
,
X5$}
Bmd
X9%
,
X5$]
Set broadcast mode to default
address
EX9%
EB
}
Bmd
X9%
,
X5$]
Clear broadcast mode
E
0EB
}
Bmd000,
X5$]
