1. Press the Esc button to clear any input buttons, output buttons, or control buttons that
may be lit.
2. Press and hold the Audio button until the button begins to blink red to enter Audio
mode. Release the button.
3. Press and release an input button to select an input that has analog audio. The output
buttons display the audio level for the selected input; the more output buttons lit, the
greater the gain or attenuation.
• Green output buttons indicate a gain (+) audio level.
• Red output buttons indicate an attenuation (–) level.
Audio gain and attenuation is displayed differently on different models.
• XTP II CrossPoint 3200 and XTP II CrossPoint 6400 — Each output button
indicates 1 dB when lit steadily (see table 3 on the next page).
• XTP II CrossPoint 1600 — Each output button indicates 1 dB when blinking and
2 dB when lit steadily (see table 4 on page 54).
4. Press and release the Esc (>) and View (<) buttons to increase and decrease the audio
level.
5. Press and release the Audio button to exit the Audio mode. The Audio button stops
blinking.
NOTES:
• Pressing the Enter or Preset button also exits Audio mode. Pressing the
Preset button changes to Recall Preset mode.
• There is one level setting per analog audio input. The audio level setting is
shared by the left and right audio inputs.
• The audio level settings are stored in non-volatile memory. When power is
removed and restored, the audio level settings are retained.
• Exiting Audio mode by pressing the Audio button always returns the I/O
configuration to video and audio selected for configuration (the Video and
Audio buttons lit).
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Operation 52
