Symbol definitions
]
= Carriage return and line feed
}
= Carriage return (no line feed) (| [Pipe] can be used interchangeably
• = space
E
= Escape key (W can be used interchangeably)
X! = Input number (for tie) 00 – 16, 32, or 64 ( 00 = untied)
X@ = Output number 01 – 16, 32, or 64
X# = Global preset number 00 – 32 (00 = current configuration, applies to view ties command only)
X$ = EDID value See table 9, beginning on page 88
X% = Input signal status 0 = No signal detected 1 = Sync detected
X^ = Input number (for other functions than tie) 01 – 16, 32, or 64
X& = Audio gain 00 – 24 (1 dB per step)
X* = Numeric dB value –18 to +24 (43 steps of gain or attenuation) (default = 0 dB)
X( = Audio attenuation 1 – 18 (1 dB per step)
X1) = Switcher model 17 = XTP II CrossPoint 1600 65 = XTP II CrossPoint 6400
33 = XTP II CrossPoint 3200
X1! = Resolution and rate for black screen 2 = 1280x720p @ 50 Hz 6 = 1920x1080p @ 60 Hz
4 = 1280x720p @ 60 Hz
X1@ = Input audio source 0 = Auto (see the example on page 90)
1 = HDMI (de-embedded digital audio) (default)
2 = Analog 2-channel audio
X1# = HDCP authorized device 0 = Off 1 = On (default)
X1$ = HDCP status (for inputs) 0 = No source device connected 2 = Source connected is not HDCP-compliant
1 = Source connected is HDCP-compliant
X1% = Captive screw or UART 0 = Captive screw RS-232 insert 1 = Ethernet RS-232 insert (UART)
(default)
X1^
= Port number 01 = Remote RS-232/RS-422 port
02 is unused
03 — 130 = UARTs 1 — 128 (XTP input and output board ports)
X1&
= Baud rate 300, 600, 1200, 1800, 2400, 3600, 4800, 7200, 9600, 14400, 19200, 28800,
38400, 57600, 115200
X1*
= Parity odd, even, none, mark, space (only the first letter required) (n = default)
X1(
= Data bits 7, 8 (default)
X2)
= Stop bits 1 (default), 2
X2!
= Port timeout interval (in 10-second increments) 1 (= 10 seconds) - 65000 (default is 30 = 300 seconds = 5 minutes)
NOTE: X1^ through X2! are repeated on page 109 as X7( through X8# and X9@.
X2@ = UART starting point The starting point (
X2@
) is the front panel RS-232/RS-422 port.
The next position (
X2@
+1
) is not used.
XTP II CrossPoint 1600 —
X2@
+2
through
X2@
+17
are XTP inputs.
XTP II CrossPoint 3200 —
X2@
+2
through
X2@
+33
are XTP inputs.
XTP II CrossPoint 6400 —
X2@
+2
through
X2@
+65
are XTP inputs.
XTP II CrossPoint 1600 —
X2@
+18
through
X2@
+34
are XTP outputs.
XTP II CrossPoint 3200 —
X2@
+34
through
X2@
+65
are XTP outputs.
XTP II CrossPoint 6400 —
X2@
+66
through
X2@
+129
are XTP outputs.
Default values: 1999 = Rear panel Remote RS-232/RS-422 port
2000 = Unused
2001 through 2016 (XTP II CrossPoint 1600) = Input 1 through 16
2001 through 2032 (XTP II CrossPoint 3200) = Input 1 through 32
2001 through 2064 (XTP II CrossPoint 6400) = Input 1 through 64
2017 through 2032 (XTP II CrossPoint 1600) = Output 1 through 16
2033 through 2064 (XTP II CrossPoint 3200) = Output 1 through 32
2065 through 2128 (XTP II CrossPoint 6400) = Output 1 through 64
X2# = Enable or disable 0 = Disable 1 = Enable
X2$ = Amount of power requested 00 or 13 (watts)
X2% = Power status 0 = Unpowered endpoint
1 = Power provided to endpoint 3 = No power available, but enabled
2 = Power available but disabled 4 = Fault
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 84
