kBox4 manual v9.5
exxentric.com/support 6
SPECIFICATIONS
Active Lite Pro
Minimum dimensions (bounding
box) - fully assembled
Width 76 (30") 76 (30") 98 (38,5")
Depth 51 (20") 51 (20") 63 (29")
Height 21 (8.5") 21 (8.5") 23 (9")
Top surface in cm (inches)
Width 68.5 (27") 68.5 (27") 90 (35.5")
Depth 43.5 (17") 43.5 (17") 55 (21.5")
Area (m

) 0.29 0.29 0.50
Materials
Chassis steel aluminium aluminium
Flywheel steel steel steel
Color bronze brown, blue, black brown, blue, black
Features
kMeter II built-in optional* yes yes
Drive belt auto-retract yes yes yes
Quick change flywheel yes yes yes
Foot block option** yes yes yes
No. of flywheels mounted 1-2 1-4 1-4
Inertia range kgm

0.005 - 0.10 0.005 - 0.20 0.005 - 0.28
Inertia factor (min to max) x20 x40 x56
Angle adjuster yes yes yes
Flywheel options (kgm
2
)
XS - 0.005 yes yes yes
S - 0.010 yes yes yes
M - 0.025 yes yes yes
L - 0.050 yes yes yes
XL - 0.070 - - yes
Weight of machine 15 kg (33 lbs) 9.5 kg (21 lbs) 15.5 kg (34 lbs)
Maximum weight allowed on kBox 200 kg (441 lbs) 200 kg (441 lbs) 200 kg (441 lbs)
*) Active is kMeter II ready. It can be pre-installed from the factory or later by the customer.
**) Pro has a larger platform and more positions for individual adjustment of the foot blocks. Included with
kBox4 Active, Lite and Pro platforms: angle adjuster, attachment kit, tool kit, printed manual, spare drive belt,
flywheel protection for mounted flywheels, built-in kMeter II (Lite and Pro only).
