EZ-ACCESS PASSPORT Instructions

Page | 4
5.
KIT CONTENTS:
DESCRIPTION
QUANTITY
(NOT
TO
SCALE)
HINGE HD STANDARD SELF CLOSING 1.53125" X 3.5625" X 4.75" 2
GATE HINGE CONNECTOR BAR .445" X 1.5" X 6" 2
PAN HEAD PHILLIPS MACHINE SCREW 1/4"-20 X 5/8" SS 4
HEADLESS SOCKET HEAD SET SCREW 5/16"-18 X 5/8" SS 4
PAN HEAD PHILLIPS MACHINE SCREW #10-24 X 3-1/2" SS 4
#10-24 LOCKNUT SS 4
#10 X 7/16" OD FLAT WASHER SS 4
PASSPORT GATE HINGE REPLACEMENT INSTRUCTIONS
1
