Three-sided Viewing Installation
1.Re-secure both side trims using the 12 screws previously removed (Fig. 3-4).
Two-sided Viewing Installation
1.For desired open side, re-secure the side trim using the 6 screws previously removed (Fig. 3-5).
2.For desired closed side, re-secure the side panel using the 4 screws previously removed (Fig. 3-5).
When installed with both sides open, the appliance will have a front view, as well as left and right-side views.
When installed fully recessed into the wall with one side open, the appliance will have a front view and left-
or right-sided view, depending on your desired open side.
