1. Ensuring the glass metal bracket is fitted to the top of the front glass, place the front glass into the
track located inside the firebox (Fig. 4-1).
2. Tilt the glass forwards and into place. (Fig. 4-2).
3. Secure the four flat head screws (supplied) through the bracket holes on the top, underside of the
glass metal bracket (Fig. 4-3).
4. Reverse these steps to remove the front glass.
