Installation / Minimum Clearance
Your appliance is a recessed and/or mantel installed appliance. Select a suitable location that is
not susceptible to moisture build-up. It must be located enough distance away from curtains, furniture
and high traffic areas. See below for more info.
NOTE: Follow all local and national electrical codes.
MINIMUM CLEARANCE TO COMBUSTIBLES
Measurements are taken from the glass front.
Bottom 0" Top 11.8" (300mm) to mantel
Sides 0" Top 11. 8" (300mm) to ceiling
Back 0" Front 36” (1000mm) to vent
MINIMUM MANTEL CLEARANCES
WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE
HEAT RESISTANT TO PREVENT DISCOLOURATION.
