Ezviz C3W User Manual

3
Step 3 Camera Installation
You can install the camera on the wall or ceiling.
•Make sure the wall is strong enough to withstand three times the weight
of the camera.
•Recommended installation height: 3m (10 ft).
1
Install the Camera
- Place drill template onto the surface you have chosen to mount the camera.
- (For the cement wall/ceiling only) Drill screw holes according to the template, and
insert three anchors.
- Use three metal screws to fix the camera base according to the template.
Mounting Template
Anchor Metal Screws
2
Adjust the Surveillance Angle
- Loosen the adjusting screw.
- Adjust the surveillance angle as your desired place.
- Tighten the adjusting screw when you have your camera in the position you want.
Make sure the microSD card slot is facing downward.

Ezviz C3W Specifications

General

Connectivity	Wi-Fi
DNR	3D DNR
Max. Resolution	1920 x 1080
Audio Input	Built-in microphone
Power Supply	DC 12V/1A
Night Vision	30m (98ft)
Lens	2.8mm @ F2.2, Horizontal angle: 103°, Diagonal angle: 118°
Day & Night	Yes
WDR	Yes
Video Compression	H.264
Wi-Fi Standard	802.11b/g/n
Frequency Range	2.4GHz
Channel Bandwidth	20MHz
Operating Conditions	-30°C to 60°C
IR Range	Up to 30m
Storage	MicroSD card
