Ezviz EB8 User Manual

6
4� Installation Steps
The camera can be wall mounted and ceiling mounted.
Ceiling/Wall Mount
1.Pleaseseparatethemountingbaseandthecamerarst.
2.Removetheprotectivelmfromthelens.
3.
Place the drill template onto a clean and flat surface.
4. (For cement wall only) Drill screw holes according to the template, and insert the anchors.
5.Usescrewstoxthemountingbaseaccordingtothetemplate.
6. Mount the camera to the mounting base.
Drilling Template
Mounting Base
Screw
Anchor
Fig. 1 Ceiling Mount

Ezviz EB8 Specifications

General

Weatherproof Rating	IP65
Audio	Two-way Audio
Image Sensor	1/2.7" Progressive Scan CMOS
Lens	4mm @ F1.6
Video Compression	H.265
Operating Temperature	-30°C to 60°C (-22°F to 140°F)
Resolution	2K (2560 × 1440)
Night Vision	Up to 30 meters
Connectivity	Wi-Fi
Storage	MicroSD card slot
Smart Features	Motion detection, Human Detection
Field of View	105°
Power	DC 12V
