SPRINT 382 - SPRINT 383 1 00058I0112 - Rev.6
Translation of the original instructions
ENGLISH
INDEX
1. WARNINGS page.2
2. TECHNICAL SPECIFICATIONS page.2
3. LAYOUT AND COMPONENTS page.2
4. ELECTRIC CONNECTIONS page.2
4.1. Connection of photocells and safety devices page.3
4.2. J7 Terminal board - Power supply (fi g. 2) page.4
4.3. J6 Terminal board - Motors and fl ashing lamp (fi g. 2) page.4
4.4. J1 Terminal board - Accessories (fi g. 2) page.4
4.5. Connector J2 - Rapid connection to 5-pin radio-receiver module page.5
4.6. Connector J6 - Limit-switches rapid connection (fi g.2) page.5
4.7. Connector J3 - Encoder rapid connection (fi g.2) page.5
5. PROGRAMMING page.6
5.1. BASIC PROGRAMMING page.6
5.2. ADVANCED PROGRAMMING page.6
6. START-UP page.7
6.1. INPUTS CHECK page.7
7. AUTOMATED SYSTEM TEST page.7
EU DECLARATION OF CONFORMITY
The Manufacturer
Company name: FAAC S.p.A. Soc. Unipersonale
Address: Via Calari, 10 - 40069 Zola Predosa BOLOGNA - ITALY
hereby declares on his sole responsibility that the following product:
Description: Control unit
Model: SPRINT 382 - SPRINT 383
complies with the following applicable EU legislations:
2014/30/EU
2014/35/EU
2011/65/EU
Furthermore, the following harmonised standards have been applied:
EN 60335-1:2012 + A1:2014
EN 61000-6-2:2005
EN 61000-6-3:2007 + A1:2011
Bologna, Italy, 01-07-2018 CEO
A. Marcellan
Notes on reading the instruction
Read this installation manual to the full before you begin installing the product.
The symbol
indicates notes that are important for the safety of persons and for the good condition of the automated system.
The symbol
draws your attention to the notes on the characteristics and operation of the product.
