Faber e-MatriX 800 - Framing the Fireplace (FEF3226 L2;L3 Option 1)

11
Installation
FEF3226L2/L3 – Framing Option 1
EXISTING WALL
26.63
677
.87
22
GAP FROM
FLOOR FOR VENTING
8.87
225
21.50
546
19.50
495
37.40
950
42.37
1076
Intake if no
clearance is left
between oor and
hearth
