Faber MatriX 800 Series User Manual

Installation Instructions Installation Instructions
26
14 Tecnical data
14.1 MatriX 800/500
II2H3+ II2H3+ II2H3+
Type appliance C11/C31/C91 C11/C31/C91 C11/C31/C91
Reference gas G20 G30 G31
Input Hi kW 9,5 9,5 9,5
Efficiency class 1 1 1
NOx-class 4 4 4
Inlet pressure mbar 20 30 37
Gas rate m³/h 1,003 0,288 0,378
(at 15º C and 1013 mbar) gr/h - 720 710
Burner pressure at full mark mbar 10,5 21 28,4
Injector main burner mm
(4x) 1,3
(1x) 1,6
(1x) 0,8
(4x) 0,9
(1x) 0,8
(4x) 0,9
Reduced input restraint mm adjustable adjustable adjustable
Pilot flame SIT145 SIT145 SIT145
Code pilot flame injector Nr.36 Nr.23 Nr.23
Diameter outlet/inlet mm 130/200 130/200 130/200
Gas controle valve GV60 GV60 GV60
Gas connection 3/8" 3/8" 3/8"
Electrical connection V 230 230 230
Batteries remote Symax V (2x) 1,5 AAA (2x) 1,5 AAA (2x) 1,5 AAA
Batteries remote ITC V (2x) 1,5 AA (2x) 1,5 AA (2x) 1,5 AA
Gas category
