FC-WALK-BEHIND-V2-OP-EN - 13 -
To program the 3 Zones, press
From here you will be prompted with a passcode screen. Enter the
manager passcode 349 to get access to setup.
Once you have entered the password, you will see the Figure 3.
screen where you can alter the name, solution output, down-pressure
setting, scrubbing speed, and vacuum power.
Alternatively you can lock the Zone out from this screen, to prohibit
operator use.
Once any of the 3 “Zones” is locked the remaining zones are no lon-
ger adjustable either by the operator.
To alter the name of a Zone, simply click on the black name box and
a full keyboard will appear as Figure 4. shows. Enter new name and
save your work with the Green save icon.
TOUCH SCREEN ZONE PROGRAMMING (OPTIONAL)
3
#1 NAME
SUDSSUDS
3
LIGHT DUTY
SUDSSUDS
To Next Page
