Operating manual
CNC 8055
CNC 8055i
EXECUTE / SIMULATE
4.
·T· MODEL
SOFT: V02.2X
·67·
Display
• The position values for the axes of the machine.
It must be borne in mind that the display format for the axes is established by machine parameter
"DFORMAT" and that real or theoretical position values will be shown depending on the setting
of machine parameter "THEODPLY".
Each axis is provided with the following fields:
COMMAND Indicates the programmed coordinate or position value which the axis must reach.
ACTUAL Indicates the actual (current) position of the axis.
TO GO Indicates the distance which is left to run to the programmed coordinate.
