Fagor CNC 8055i User Manual

·8·
CNC 8055
CNC 8055i
Version history
Software V01.31 October 2011
Software V01.40 January 2012
Software V01.60 December 2013
Software V01.65 January 2015
Software V02.00 February 2014
List of features Manual
CNC 8055 FL Engraving model INST / OPT/ PRG
List of features Manual
Execution of M3, M4 and M5 using PLC marks INST / PRG
Values 12 and 43 of variable OPMODE in conversational work mode. INST / PRG
List of features Manual
Auto-adjustment of axis machine parameter DERGAIN. INST
New value for axis machine parameter ACFGAIN (P46). INST
Value 120 of the OPMODE variable. INST / PRG
List of features Manual
Block processing time of 1 ms on the "CNC 8055i FL Engraving" model. INST / OPT/ PRG
List of features Manual
Profile machining in segments. J parameter for G66 and G68 cycles. PRG
Calls to subroutines using G functions. INST / PRG
Anticipated tool management. INST
Managing "PNG" and "JPG" graphic elements. INST
New values for parameters MAXGEAR1..4 (P2..5), SLIMIT (P66) and MAXSPEED (P0). INST
Retracing function of 2000 blocks. INST
Quick block search. OPT
Local subroutines within a program. PRG
Avoid spindle stop with M30 or RESET. Spindle parameter SPDLSTOP (P87). INST
Programming T and M06 with associated with a subroutine in the same line. PRG
New values of the OPMODE variable. INST / PRG
New variables: DISABMOD, GGSN, GGSO, GGSP, GGSQ, CYCCHORDERR. INST / PRG
Possibility to set the parameters of SERCOS nodes in a non-sequential order. INST
WRITE instruction: “$” character followed by “P”. PRG
Cancel additive handwheel offset with G04 K0. General parameter ADIMPG (P176). INST / PRG
Ethernet parameter NFSPROTO (P32). TCP or UDP protocol selection. INST
Face thread repair cycle. OPT TC
Penetration increment (step) in thread repair. INST / OPT TC
API compliant thread. OPT TC
Roughing by segments in inside profiling cycles 1 and 2. INST / OPT TC
Programming the Z increment and the angle on threads. INST / OPT TC
Reversal of the starting and final point of the face thread repair. INST / OPT TC
Manual tool calibration without stopping the spindle during each step. INST / OPT TC
