Operating manual
CNC 8055
CNC 8055i
8.
UTILITIES
·T· MODEL
SOFT: V02.2X
Accessing the programs without using the explorer
8.1 Accessing the programs without using the explorer
8.1.1 Folder
To access the part-program directory of the RAM memory, hard disk (KeyCF), USB disk and of the
external devices (serial line). The subroutine directory of the CNC can also be accessed.
Program directory
By default, the CNC shows the program directory of the RAM memory, to view another directory,
press the corresponding softkey.
On each directory, the CNC shows all the programs visible (not hidden) to the user, that is:
• Part programs
• Screen customizing programs
• The PLC program (PLC_PRG)
• The PLC error file (PLC_ERR)
• The PLC message file (PLC_MSG)
The program directory has the following definition fields:
Program
It shows the number when it is a part-program or a customizing program and the corresponding
mnemonic when it is a PLC program, the PLC error file or the PLC message file.
Comment
Any program may have a comment associated with it for its identification.
The comments may be defined when editing the program or in this operating mode using the
Rename option as described later on.
Size
It indicates, in bytes, the size of the program text. It must be borne in mind that the actual size of
the program is slightly greater because this field does not include the space occupied by some
variables used internally (header, etc.).
Date and time
The date and the time when the program was edited (last changed).
