DDS
HARDWARE
AUXILIARY MODULES
Besides the power supplies and the drives that make up the FAGOR DDS
system, there is a set of auxiliary modules that are also part of the system
and are used to perform a specific function.
Hence, we refer to:
 MAIN FILTER
MAIN FILTER 42A-A
MAIN FILTER 75A-A
MAIN FILTER 130A-A
MAIN FILTER 180A-A
 CHOKES
CHOKE XPS-25
CHOKE XPS-65-A
CHOKE RPS-75-3
CHOKE RPS-45
CHOKE RPS-20
 Resistor modules
External resistors ER+TH-/ with thermostat
External resistors ER+TH-18/+FAN with thermostat and fan
 Capacitor module
CM-1.75
 Auxiliary power supply module
APS-24
 Bus Protection Module
BPM
The following sections analyze all of them showing their technical
characteristics and other considerations.
