Fagor DDS AXD/SPD 2.50 User Manual

Cables
7.
Ref.1912
DDS
HARDWARE
· 242 ·
7.2 Power cable. Motor-drive connection
Table T. H7/4 and table T. H7/5 show the range of power cables supplied by
FAGOR to connect a motor and a drive. They are supplied without
connectors because the power connector will usually be different
depending on the motor it will be connected to. The number of meters
available upon request. It is available in lengths of 5, 10, 15, 20, 30, 40, 50,
75, 100, 150, 200, 250 and 300 meters for sections up to 10 mm² (included)
and 5, 7, 10, 12, 15, 20, 25, 30, 35, 40, 45, 50, 75 and 100 for sections of
up to 50 mm² (included). Their sales model is:
The mechanical characteristics of the power terminals (U, V, W, PE) on
modular drives are:
For further details on the connector that must be mounted at the end of the
MPC cable and connected at the motor end, see the manual of the
corresponding motor.
MPC-4
x to connect motors without brake
MPC-4
x+(2x) to connect motors with brake
T. H7/4 Range of cables to connect a motor (without brake) and a drive.
MPC-4x1.5 MPC-4x4 MPC-4x10 MPC-4x25 MPC-4x50
MPC-4x2.5 MPC-4x6 MPC-4x16 MPC-4x35 MPC-4x70
T. H7/5 Range of cables to connect a motor (with brake) and a drive.
MPC-4x1.5+(2x1) MPC-4x6+(2x1) MPC-4x25+(2x1)
MPC-4x2.5+(2x1) MPC-4x10+(2x1)
MPC-4x4+(2x1) MPC-4x16+(2x1.5)
INFORMATION. Remember that when a motor is mentioned here, it refers
to any motor of the FAGOR catalog, both synchronous and asynchronous.
MANDATORY. In order for the system to comply with the European
Directive on Electromagnetic Compatibility 2014/30/EU, the cable hose that
carries 6 or 4 cables, depending on whether the motor has a brake or not,
must be shielded and connected at both ends; i.e. both at the drive end and
a the motor end. This condition is a must.
i
T. H7/6 Mechanical characteristics of the power connectors of the modular
drives.
Module Gap Max.
tightenin
torque
Max.
hole
section
Conductor
section
mm N·m mm² mm²
AXD/SPD/MMC 1.08/1.15 7.62 0.6 4 2.5
AXD/SPD/MMC 1.25 7.62 0.8 6 6
AXD/SPD/MMC 1.35 10.16 1.5 6 6
AXD/SPD/MMC 2.
 10.16 1.8 16 16
SPD 2.85 10.16 1.8 16 16
AXD/SPD/MMC 3.100 - 8 50 25
AXD/SPD/MMC 3.150 - 8 50 50
SPD 3.200 - 20 95 70
SPD 3.250 - 20 95 95
MANDATORY. The cable wires connected at the motor end must be kept
inside their corresponding connector. The connector will be different
depending on the user's motor.
