Description
1.
32
Ref.1912
DDS
HARDWARE
· 28 ·
1.1 Description
Fagor Automation's DDS system has a modular stackable design.
It may be connected directly to a TN type three-phase mains with a frequency
of 50/60 Hz and with a rated voltage between 400-10 % and 460+10 % V AC.
This system supplies the electric motors with a three-phase voltage of 400-
4.5 % V AC and a variable frequency with which it will govern its speed.
Certain mandatory protection devices must be added between the mains lines
and the DDS system. Others may be optional. These elements are:
According to the user's needs, the DDS system may consist of the following
modules:
Main switch Mandatory
Fuses Mandatory
Differential breaker Optional
Transformer or auto-transformer Optional
Power switch Mandatory
Power supplies
Non-regenerative power supplies PS
Regenerative power supplies XPS
Regenerative regulated power supplies
(rectifier/booster)
RPS
Auxiliary power supply APS-24
Modular drives
Axis velocity and position control AXD
Spindle velocity and position control SPD
Axis velocity and position control.
It is capable of generating a path on its own.
MMC
Compact drives
Axis velocity and position control ACD
Spindle velocity and position control SCD
Axis velocity and position control.
It is capable of generating a path on its own.
CMC
Auxiliary modules
Capacitor Module CM-1.75
Bus Protection Module BPM
MAINS FILTERS (mandatory)
MAIN FILTER-
A
MAIN FILTER-
A-A
CHOKES
required with XPS and RPS power supplies
CHOKE XPS-
-
CHOKE RPS-75-3
CHOKE RPS-

Resistor modules
ER+TH-
/,
ER+TH-18/
+FAN
INFORMATION. The DDS system has been manufactured in accordance with
EN 60204-1 in compliance with European Directive 2014/35/EU on Low
Voltage.
i
