Dimensions
DIMENSIONS
Modular drives
11.
Ref.1912
· 369 ·
DDS
HARDWARE
11.2 Modular drives
AXD/SPD/MMC 1.08, AXD/SPD/MMC 1.15
F. H11/10
Modular drives, AXD/SPD/MMC 1.08 | 1.15. Dimensions.
255
389
347
45
373
77
266.5
Dimensions in mm. 1 in = 25.4 mm
R3.5
8.5
22
R3.5
R6.5
8
7.5
