Dimensions
DIMENSIONS
Compact drives
11.
Ref.1912
· 377 ·
DDS
HARDWARE
ACD/SCD/CMC 2.35, ACD/SCD/CMC 2.50, ACD/SCD/CMC 2.75
F. H11/18
Compact drives, ACD/SCD/CMC 2.35 | 2.50 | 2.75. Dimensions.
389
347
255
77
373
398.5
266
117
Dimensions in mm. 1 in = 25.4 mm
R3.5
8.5
22
R3.5
R6.5
8
7.5
