Fagor DDS AXD/SPD 2.50 User Manual

Drives
3.
180
Ref.1912
DDS
HARDWARE
· 98 ·
Technical data
There are specific modular drives AXD/MMC to control synchronous motors (both for feed axis and
spindle applications) and SPD to control asynchronous motors (in spindle applications). This chapter is
common to both models because their external characteristics (dimensions, connectors, ...) are the
same.
Note that:
MMC drives have the same currents as AXD drives.
fc. It represents the switching frequency of the IGBT's.
The dissipated powers correspond to the operation at the rated current in S1 mode.
See the load duty cycle for the modular drives in the corresponding section of this chapter.
T. H3/1 Currents on modular drives for synchronous motors. fc = 4 kHz.
With internal fan
Drive for synchronous motor (as feed axis)
Models
AXD
MMC
1.08
AXD
MMC
1.15
AXD
MMC
1.25
AXD
MMC
1.35
AXD
MMC
2.50
AXD
MMC
2.75
AXD
MMC
3.100
AXD
MMC
3.150
MMC
3.200
I S1= In (A) 4.0 7.5 12.5 17.5 25.0 37.5 50.0 75.0 90.0
Imax S1 (A) 8.0 15.0 25.0 35.0 50.0 75.0 100.0 150.0 180.0
Dissipated power (W) 33 69 88 156 225 270 351 536 834
T. H3/2 Currents on modular drives for synchronous motors. fc = 8 kHz.
With internal fan
Drive for synchronous motor (as feed axis)
Models
AXD
MMC
1.08
AXD
MMC
1.15
AXD
MMC
1.25
AXD
MMC
1.35
AXD
MMC
2.50
AXD
MMC
2.75
AXD
MMC
3.100
AXD
MMC
3.150
MMC
3.200
I S1= In (A) 4.0 7.5 12.5 17.5 25.0 37.5 50.0 75.0 90.0
Imax S1 (A) 8.0 15.0 25.0 35.0 50.0 75.0 100.0 150.0 180.0
Dissipated power (W) 44 89 132 195 305 389 510 605 840
T. H3/3 Current in modular drives for synchronous or asynchronous motors. fc = 4 kHz.
With internal fan
Drive for synchronous or asynchronous motor (as spindle)
Models
SPD
1.15
SPD
1.25
SPD
1.35
SPD
2.50
SPD
2.75
SPD
2.85
SPD
3.100
SPD
3.150
SPD
3.200
SPD
3.250
I S1= In (A) 10.5 16.0 23.1 31.0 42.0 50.0 70.0 90.0 121.0 135.0
0.7 x In (A) 7.3 11.2 16.1 21.7 29.0 35.0 49.0 63.0 84.7 94.5
I S6-40 (A) 13.7 20.8 30.0 40.3 54.6 65.0 91.0 117.0 157.3 175.5
Dissipated power (W) 98 110 195 349 289 432 496 626 1163 1333
T. H3/4 Current in modular drives for synchronous or asynchronous motors. fc = 8 kHz.
With internal fan
Drive for synchronous or asynchronous motor (as spindle)
Models
SPD
1.15
SPD
1.25
SPD
1.35
SPD
2.50
SPD
2.75
SPD
2.85
SPD
3.100
SPD
3.150
SPD
3.200
SPD
3.250
I S1= In (A) 10.5 13.0 18.0 27.0 32.0 37.0 56.0 70.0 97.0 108.0
0.7 x In (A) 7.3 9.1 12.6 18.9 22.4 25.9 39.2 49.7 67.9 75.6
I S6-40 (A) 11.6 16.9 23.4 35.1 41.6 48.1 72.8 91.0 126.1 140.4
Dissipated power (W) 98 130 201 350 333 438 546 668 1187 1344
