Fairchild T6000 - Installation and Mounting; Mounting Kit 16799-1; DIN Rail Mounting Kit 16893; Mounting Kit 19254-1

3
NOTE: The TR6000 Transducer is designed for use
with the TR Rack Kit. Physically, it is the same as the
TT6000 (Terminal Block) Unit except that the terminal
block has been rotated to the rear. For detailed infor-
mation, see Figure 4. “TR6000 Outline Dimensions”
on page 1.
The Model T6000 is supplied with a DIN Rail Mounting
Kit 16893. For detailed information, see Figure 7. A
Mounting Kit 19254-1 is available when installing the
unit on a 2" pipe, see Figure 8.
Figure 8. Mounting Kit 19254-1 (Sold Separately)
Installation
Figure 7. DIN Rail Mounting Kit 16893 (Included with Unit)
Figure 6. Mounting Kit 16799-1
(Included with Unit)
9/32
7.1
2 7/16
61.9
Mounting Kit 16799-1
Includes the following:
Two 10-32 x 5/16” Screws
Mounting Bracket Two 1/4” NPT Pipe Plugs
Two 7/16” Thick Spacers (not used on T6000)
17/64
6.6
5/8
15.9
1/8
3.0
1
25.4
3/4
19.1
2 1/4
57.2
2 7/8
73.2
1 1/2
38.1
1
25.4
9/32
7.1
3/8
9.5
3/4
19.0
4 1/2
114.3
4 55/64
123.4
1
25.7
Use two
1/4"-20
Screws for
Mounting
(not included
in mounting kit)
ZERO
SPAN
OUT
OUT
IN
IN
DIN
EN-50045
3 7/16
87.1
DIN
EN-50022
DIN
EN-50035
39/64
15.6
53/64
20.9
19/32
14.9
3 13/32
86.6
3 5/16
84.3
Din Rail
Mounting
Configuration
shown with
Model TD6000
& Din EN-50045
2" Pipe Mounting
Configuration
shown with
Model TT6000
1
25.4
2 21/32
67.6
3 1/2
88.9
Mounting Kit 19254-1
includes the following:
Mounting Bracket 2" Pipe Clamp
Two 10-32 x 5/16" Screws
11/32
8.6
1
25.4
