D100/200 Series Service Manual
Screws
Screws
Part
Number
Specify
Finish
Description Application
Size Type Use Door Thickness
Keyed, Single Conventional Cylinder
B600-100 1/4”-28 x 1-15/16” POH mach. Mounting 1-3/8” - 1-3/4”
B600-101 1/4”-28 x 1-15/16” POH mach. Mounting 1-3/4” - 2-1/4”
B600-066 • 6-32 x 1/4” PH mach. Turn -
B300-108 10-32 x 3/8” PH mach. Anti-pry shield -
Keyed, Single SFIC Cylinder
B600-100 1/4”-28 x 1-15/16” POH mach. Mounting 1-3/8” - 2-1/4”
B600-066 • 6-32 x 1/4” PH mach. Turn -
Keyed, Double Conventional Cylinder
B600-047 1/4”-28 x 3-13/16” PH mach. Mounting 1-3/8” - 1-3/4”
B600-078 1/4”-28 x 3-29/64” PH mach. Mounting 1-3/4” - 2-1/4”
B300-108 10-32 x 3/8” PH mach. Anti-pry shield -
Keyed, Double SFIC Cylinder
B600-053 1/4”-28 x 3-61/64” PH mach. Mounting 1-3/4” - 2-1/4”
B300-108 10-32 x 3/8” PH mach. Anti-pry shield -
Keyless, D261
B600-066 • 6-32 x 1/4” PH mach. Turn -
B600-048 10-32 x 1/2” PH mach. Mounting plate -
F506-359 #8 x 3/4” RH wood Mounting plate -
Keyless, D261M, D271
B520-662 10-32 x 1-3/4” POH mach. Mounting 1-3/8” - 1-3/4”
B520-663 10-32 x 1-3/4” POH mach. Mounting 1-3/4” - 2-1/4”
B600-066 • 6-32 x 1/4” PH mach. Turn -
All Functions
C603-897 • #8 x 3/4” PFH combo Deadbolt & strike -
J520-028 #8 x 2” PFH wood 2” strike screw -
R525-256 #12 x 3” PFH wood 3” metal dust box -
