APPENDIX A
SERIAL INTERFACE
The Falcon Fusion uses a standard interface cable along with an
adapter to connect to various alarm panels except the DSC
Power Series and the IDS805 which use a key-bus module.
The cable ends are interchangeable.
The following adapter boards are available:
ALARM PANEL ADAPTER
Rhino
Texecom Premier
IDS
Paradox
Pima
Pima (4 pin)
Paradox (4 pin)
Texecom-IDS (5 pin)
No adapter
VERY IMPORTANT: Plug the adapter board into the alarm panel and
NOT the Falcon Fusion.
Texecom-IDS (5 pin)
DSC Neo
DSC Neo (5 pin)
DSC Power Series
IDS805
DSC Power Series/IDS805 FSK Key-Bus Module
DSC Power Series/IDS805 FSK Key-Bus Module
Risco LightSYS 2
Risco (3 pin)
I Falcon Fusion Installation and Operation Manual
