The Pima serial interface will send the standard FSK Contact ID
alarm codes.
DSC NEO SERIAL INTERFACE
Set the serial port format to DSC PowerSeries Neo on the Falcon
Fusion (Refer to Section 3.4). The Falcon Fusion can send
alarms received from the PC LINK_2 header of the DSC
PowerSeries Neo panel.
Plug the adapter marked DSC PowerSeries Neo Adapter into the
PC LINK_2 header on the alarm panel. Plug the other end into
the Falcon Fusion’s serial port.
Proceed to program the panel as per the Falcon Connection &
App Set-up Guide provided, for alarm signals to be sent and/or
DSC POWERSERIES FSK KEY-BUS MODULE
The Falcon Fusion can send alarms received from the keypad-
bus of the DSC PowerSeries alarm panel.
Wire the DSC PowerSeries FSK Key-bus Module to the keypad-
bus on the alarm panel and then connect the 4-pin molex
connector to the serial port of the Falcon Fusion.
Proceed to program the panel as per the Falcon Connection &
Falcon Fusion Installation and Operation Manual I
25
