Falcon T Series Service Manual

T-Series Service Manual
47
Levers
SFIC/IC Levers
Style Part Number Description
Avalon
030740-002-xxx Standard SFIC Lever
030926-001-xxx Assa, Medeco, Yale IC Lever
030927-001-xxx Schlage IC Lever
030928-001-xxx Corbin Russwin IC Lever
030930-001-xxx Sargent IC Lever
Dane
030742-002-xxx Standard SFIC Lever
030926-002-xxx Assa, Medeco, Yale IC Lever
030927-002-xxx Schlage IC Lever
030928-002-xxx Corbin Russwin IC Lever
030930-002-xxx Sargent IC Lever
Quantum
030744-002-xxx Standard SFIC Lever
030926-003-xxx Assa, Medeco, Yale IC Lever
030927-003-xxx Schlage IC Lever
030928-003-xxx Corbin Russwin IC Lever
030930-003-xxx Sargent IC Lever
Notes: 1) Specify finish on end of part number (ex. 030740-000-626)
Spring Cage Replacement Kits
Q330-270 - Locking Spring Cage Q330-271 - Non-Locking Spring Cage
Apply light film of M204-250 on surfaces with brush or equivalent.
Barrel or tumble with M204-250 to acheive approximately .015-.040 film thickness

Falcon T Series Specifications

General

Grade	ANSI/BHMA Grade 2
Keypad	Yes
Backup Key	Yes
Type	Electronic Lock
Backset	Adjustable 2-3/8" or 2-3/4"
Material	Metal
Finishes	Satin Nickel
Power Source	Battery
Battery Life	Approximately 1 year
Auto-Lock	Yes
Installation	Easy installation with a screwdriver
