Falltech Confined Space Davit System - Page 10

021519
MCS30 Rev B
10
Figure 20 Figure 21
4.5 Conned Space Davit System Assembly
Place the Portable Base in the locaon suitable for the applicaon. Insert the Lower Mast Extension, see Figure 22, into the Portable Base
sleeve with the posion liming bolt toward the front of the base as shown in Figure 23.
Li the Davit Arm and place if onto the Lower Mast Extension, see Figure 24. Ensure the bolt on the Lower Mast Extension ts into the
Davit Arm mang notch as shown in Figure 25.
Figure 24 Figure 25
Figure 22 Figure 23
