Falltech Confined Space Davit System - Page 11

021519
MCS30 Rev B
11
4.6 Leveling
When using the Conned Space Davit System, the base must be level at all mes with the legs pinned and ghtened in place.
To level of the davit, adjust each leg height unl the bubble is centered in the bubble level, see Figure 26.
4.7 Fine Oset Adjustment
The Conned Space Davit System is equipped with a ne adjustment screw to help ensure the anchor point is centered over the
entry/egress locaon. To adjust, turn the ne adjustment screw to raise and lower the arm to the desired posion, see Figure 27.
Figure 26 Figure 27
4.8 Winch/3-Way Installaon
Based on your applicaon, aach the FallTech Davit Device Receiver Bracket to the davit using the provided detent pins. See Figure 28 for
correct and Figure 29 for incorrect orientaons of the Davit Receiver Bracket. DO NOT mount any device on the front of the lower mast.
Figure 28 - Correct Device Bracket Mounng
Figure 29 - Incorrect Device Bracket Mounng
