FALMEC Massimo INSERT User Manual

7
47
3/4
" (1213 mm)
37
11/16
" (957 mm)
46
7/16
" (1180 mm)
12
9/16
" (319 mm)
23
3/4
" (603 mm)
22
7/16
" (570 mm)
7
3/4
"
(197 mm)
5
15/16
"
(Ø 150 mm)
46
9/16
" (1183 mm)
22
9/16
" (573 mm)
23
3/4
" (603 mm)
11
7/16
" (290 mm)
11
13/16
" (300 mm)
11
9/16
" (294 mm)
5/8"
(16 mm)
5/8 "
(16 mm)
5
7/8
"
(150 mm)
3/8"
(9,5 mm)
EN - CUTOUT MEASUREMENTS FOR INSTALLATION
FR - MESURES DU TROU POUR ENCASTREMENT
ES - MEDIDAS DEL ORIFICIO PARA EMPOTRADO
IT - MISURE FORO PER INCASSO
64 lb
29 kg
MASSIMO 48"
2 MOTOR
Cod: FIMAX46B9SS-1
120Vac, 60Hz 540W
EN - cable length 5,0ft (1,5m)
FR - longueur de câble 5,0ft (1,5m)
ES - longueur de câble 5,0ft (1,5m)
IT - lunghezza cavo 5,0ft (1,5m)

FALMEC Massimo INSERT Specifications

General

Brand	FALMEC
Model	Massimo INSERT
Category	Ventilation Hood
Language	English
