USER MANUAL FOR FT TOWERS 17
Figure 43
Place the reinforcement bars and fix them with
its pins to the frontal legs.
Figure 44
Place the tower in its working position and level
until the bubble level is centered. Wheels should
not come into contact with the ground
Calculate the load to be lifted with the tower. An
example of basic load calculation is attached.
Figure 45
In this example we have obtained a weight of
238,5 kg.
With that load, see what position the load should
have on the forks of the tower. Take into account
that the inclination of the loudspeakers and the
bumper should not support any part of the
tower.
Figure 46
Choose the FT tower model. Check for the value
immediately above the load you need. With this
value, take the exact position to which the
accessory for flying must be placed.
