Fantek FT-7045 - Load Chart

USER MANUAL FOR FT TOWERS 31
Figure 89
1
ATF2DS
3
ATF17PAM
5
ATFT200
7
ATF17PA
2
ATF1DS
4
ATF08PAM
6
ATFT600
8
ATF08PA
Figure 90
PART.
FT6860
FT7045
FT6033
FT6520
FT5323
ATF1DS
X
X
X
ATF2DS
X
X
ATF17PA
X
X
X
ATF08PA
X
X
ATFT200
X
X
X
ATFT600
X
X
ATF17PAM
X
X
X
ATF08PAM
X
X
Figure 91
PLACING THE LOAD
1. Determine the position where the load will be placed and consult the tower capacity. Never
exceed.
2. The “X” distance between the load is taken from the carriage to the end of the horns.
