USER MANUAL FOR FT TOWERS 29
Figure 86
To descend the load. Tense the cable and unlock
the first security system. Turn the winch while
keeping the safety system unlocked with your
other hand. If the safety system is not operated
with one hand, the tower will descend until it is
locked.
Once the load is descended, block all sections
and follow steps 4 to 1 (in that order).
Figure 87
Figure 88
WARNING! If the tower is attempted to go down
without tension in the cable and any of the safety
systems are activated, a dangerous situation will
occur because the load will descend very
abruptly, being able to destabilize the whole
installation and incurring in a serious accident.
IMPORTANT ¡!! FOR THIS PURPOSE, USE
ONLY MANUAL HOISTS
