If any one of these parts is damaged, the
whole chain assembly (sprocket, chain and
ring gear) must be replaced.
Also check the chain guide (8) and chain
slider (7).
LUBRICATION AND CLEANING
The chain should always be kept well lubricat-
ed and must be cleaned especially after having
been o road with mud or sand. Whenever there
are dry or rusted parts, if there are crushed or
bound links, the chain must be lubricated and
the deteriorated parts restored to working condi-
tion. It this is impossible, consult a Dealer.
Do not clean the chain with jets of water or
steam, high-pressure water jets or highly in-
flammable solvents.
See the LUBRICANTS table on page 130 for
products recommended for lubricating and
cleaning the chain.
AIR FILTER
Do not use petrol or inflammable solvents for
cleaning the filter to avoid the risk of fire or ex-
plosion.
For the maintenance intervals, see page 61 (PE-
RIODIC MAINTENANCE CHARTS) under:
- Air filter.
REPLACEMENT OF AIR FILTER
- Remove the saddle.
-Unscrew and remove the screw shown in the
picture below.
- Unscrew and remove the screw (1).
NOTE: THE TYPE OF FILTER DOES NOT RE-
QUIRE CLEANING BUT ONLY REPLACEMENT
which must occur every 3000km (1800ml)
for road use and at least every 1000 km for o-road
use.
-
Replace the filter (2) with a new one of the
same type.
When reassembling:
- Insert the filter in the seat of the filter box.
- Manually tighten the screw (1).
NOTE: Use a cloth to clean the inside of the filter
box before inserting the filter to keep dust and
foreign objects from entering the intake mani
fold.
- Lift the battery support tray "3" positioning
it laterally as illustrated
- Remove the filter (2)
