Cooker hood
Min.65 cm.(With Hood)
Min. 70 cm. (Without Hood)
Min.60 cm.
Min.42 cm.
Min.42 cm.
Min.60 cm.
Min.42 cm.
Cooker hood
Min.42 cm.
Min.65 cm.(With Hood)
Min. 70 cm. (Without Hood)
Figure 1
ENGLISH
e. e hoods must be installed according to the
requuirements in the hood handbook.
f. Should the coooker be installed beneath a
wall cabbinet, the latter should be situated at
least 70cm away from the hobs as indicated
in gure 1.
g. e cut-out foor the cooker cabinet should
have the dimensions indicated in the gure 1.
h. e wall in contact with the back of the
cooker must be of ameproof material.
