III- 20
COMPATIBLE 4-WIRE SMOKE DETECTORS
(Cont'd)
FOR 15220A AND 15240A FIRE ALARM CONTROL PANELS
Compatible 4-Wire Smoke Detectors must have a minimum absolute voltage range of 19 to 28 V.D.C.
DECTECTOR MANUFACTURER MAXIMUM MAXIMUM
W/BASE DETECTOR STANDBY ALARM
ORDER NO. W/BASE CURRENT CURRENT NOTES
SYSTEM SENSOR, DIV. of PITWAY CORP.
9377 1424 0.100ma. 41ma. MUST USE EOL RELAY
9378 2424 0.120ma. 41ma. MUST USE EOL RELAY
9779 2424TH 0.120ma. 41ma. MUST USE EOL RELAY
9337 1112/24 0.050ma. 25ma. MUST USE EOL RELAY
9338 2112/24 0.050ma. 25ma. MUST USE EOL RELAY
9339 2112/24T 0.050ma. 25ma. MUST USE EOL RELAY
9340 2112/24TSRB 15ma. 45ma. MUST USE EOL RELAY
9358 W/9362 1451 W/B402B 0.120ma. 41ma. MUST USE EOL RELAY
9359 W/9362 2451 W/B402B 0.120ma. 41ma. MUST USE EOL RELAY
9360 W/9362 2451TH W/B402B 0.120ma. 41ma. MUST USE EOL RELAY
9447 W/9362 5451 W/B402B 0.120ma. 39ma. MUST USE EOL RELAY
9421 W/9362 4451HT W/B402B 0.120ma. 39ma. MUST USE EOL RELAY
9440 DH1851DC 0.120ma. 41ma. MUST USE EOL RELAY
9437 DH2851DC 0.120ma. 41ma. MUST USE EOL RELAY
9164 DH400ACDCI 25ma. 100ma. MUST USE 6 WIRES
9165 DH400ACDCP 25ma. 100ma. MUST USE 6 WIRES
9175 6424 10ma. 10ma. MUST USE EOL RELAY
AND 6 WIRES
NOTE: For specific wiring and installation information read the instructions provided with each device.
