The FARHO heater will be mechanically secured to the wall at its top
by means of the brackets that have been specially designed to this end,
and which are supplied with the appliance.
Said brackets will be fitted at a centre distance of (Distance A); a
distance that is set in Table 1 for the different models, and at height
of 600 mm from the floor (Height B).
20
FITTING
Table 1
INITIAL POSITION
Fitting of Heater Brackets
Farho low-consumption heaters
Model Distance A mm.
FITTING THE RADIATOR
EXAMPLE RAD. A-7
DISTANCE
A = 480
FITTED RADIA
TOR
DISTANCE B = 600 mm.
