Farm King Model 1060 User Manual

174 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

6990633 (1-13) Printed in U.S.A. © Bobcat Company 2013

OPERATOR AND PARTS MANUAL

Backsaver Auger

Model 1050, 1060, 1070 and 1080

062013 | Rev 1 | 88664296

082014

FK306

Revision 1

Table of Contents

Questions and Answers:

H
Holly TaylorAug 8, 2025
Why is my Farm King Farm Equipment auger plugging?
- S
  Samuel DavisAug 9, 2025
  The auger might be plugging due to several reasons. It could be caused by improper PTO speed, so adjust the PTO speed accordingly. Overloading the hopper or auger can also cause plugging, so reduce the flow rate into the intake hopper. Foreign objects, wet grain, or snow/ice in the grain can also lead to this issue; in these cases, disconnect the PTO driveline and remove any foreign objects, or reduce the flow rate into the intake hopper.
Z
zandrewsAug 14, 2025
Why is my Farm King Farm Equipment grain flow too slow?
- W
  wilsonannaAug 14, 2025
  The grain flow might be too slow because the discharge gates are not open enough; open the gates to allow a faster grain flow to the hopper intake auger. Also, check that the tractor RPM isn't set too low; raise the tractor RPM to the proper setting.
J
John YoungAug 20, 2025
What to do if Farm King Farm Equipment grain flow is too fast?
- J
  John GrahamAug 20, 2025
  If the grain flow is too fast, it's likely that the discharge gate(s) are open too far. Close the gate(s) to allow a slower grain flow to the hopper / intake auger.
E
Elizabeth ClarkAug 27, 2025
Why Farm King Farm Equipment augers cannot start?
- K
  Kevin Wells DDSAug 27, 2025
  If the augers cannot start, it may be due to a plugged auger or obstruction. Shut off the tractor, disconnect the PTO, and remove the obstruction. Another possible cause is bearing failure, so check the bearings and replace them if required.
J
Javier WalkerSep 2, 2025
How to fix excessive auger vibration in Farm King Farm Equipment?
- S
  steven88Sep 2, 2025
  Excessive auger vibration can stem from several causes. Damaged flighting or tube may be the culprit, so replace the flighting and/or tube. Bent auger flighting can also cause vibration; remove the flighting, inspect for straightness, and straighten and reinstall if a bend is detected. Improper PTO speed can also lead to vibration, so adjust the PTO speed.
