CAUTION
Check the lifting capacity and stability of the tractor making sure the following relations are complied with
(see table below for definitions):
• M x (S1+S2) ≤ 0.2 x T x i + Z x (d+i)
• M ≤ 0.3T
If this not occurs, apply the front ballast required. To determine the appropriate characteristics of
the ballast, refer to the manual of the tractor.
T
Z
M
0.2 T
d i s1 s2
i = Tractor wheelbase (cm)
d = Distance between front axle and ballast center of mass (cm)
T = Weight of tractor + operator (75 kg)
Z = Ballast weight (kg)
M = Implement weight (kg)
s1 = Distance between rear axle and lower hitch points (cm)
s2 = Distance between lower hitch points and implement center of mass = 61 cm
5. OPERATING
Before operate the Flail Mower, make sure you have read and understood the operating manuals of the
Flail Mower, tractor and PTO shaft, and followed what is described in the section “Set Up”.
DANGER
During operation, adjustment, maintenance, repairing or transportation of the machine, the operator must
always use appropriate Personal Protective Equipment (PPE).
Before starting work, ensure that all machine guards are in good conditions and fully functional.
During operation, the machine can throw material from the back: prevent people and animals to approach
the operational area.
5.1. START-UP
WARNING
Before conducting the above inspections and service, make sure the tractor engine is off, all rotation parts
are completely stopped and the tractor is in park with the parking brake engaged. Make sure the machine
is resting on the ground or securely blocked up and the tractor lifting hydraulics locked.
