4.1
HYDRAULIC
SCHEMATICS
GR3
Hydraulic schematic for crane - versions
CODE DESCRIPTION
DI341
DISTRIBUTOR
DV007 DEVIATOR
VA102 DOUBLE EFFECT BLOCK VALVE
VA185 SELECTOR VALVE
VA215 OIL FLOW CHECK VALVE
VA227 SEQUENCE VALVE
VA232 UNIDIRECTIONAL VALVE
VA239 SIMPLE EFFECT BLOCK VALVE
VA247 OIL FLOW REGULATOR VALVE FOR ROTATION CYLINDER
