8. Specifications of Motor
MODEL
EzM-20
series
EzM-28
series
EzM-35
series
EzM-42
series
UNIT 20M 20L 28S 28M 28L 35M 35L 42S 42M 42L 42XL
DRIVE METHOD
-
BI-POLAR
NUMBER OF PHASES
-
2 2 2 2 2 2 2 2 2 2 2
CURRENT per PHASE
A
0.5 0.5 0.95 0.95 0.95 1.5 1.5 1.2 1.2 1.2 1.2
HOLDING TORQUE
N·m
0.016 0.025 0.069 0.098 0.118 0.13 0.23 0.32 0.44 0.5 0.65
ROTOR INERTIA
g·c m
2
2.5 3.3 9.0 13 18 15 20 35 54 77 114
WEIGHTS
g
79 104 147 204 232 194 226 299 364 433 567
LENGTH(L)
mm
28 38 32 45 50 32 36 34 40 48 60
PERMISSIBLE
OVERHUNG LOAD
(DISTANCE FROM
END OF SHAFT)
3mm
N
18 18 30 30 30 22 22 22 22 22 22
8mm
30 30 38 38 38 26 26 26 26 26 26
13mm
- - 53 53 53 33 33 3 3 33 33 33
18mm
- - - - - 46 46 46 46 46 46
PERMISSIBLE THRUST LOAD
N
Lower than motor weight
INSULATION RESISTANCE
Mohm
100 MIN.(at 500VDC)
INSULATION CLASS
-
CLASS B(130℃)
OPERATING TEMPERATURE ℃
0 to 55
MODEL
EzM-56
series
EzM-60
series
EzM-86
series
UNIT 56S 56M 56L 60S 60M 60L 86M 86L 86XL
DRIVE METHOD
-
BI-POLAR
NUMBER OF PHASES
-
2 2 2 2 2 2 2 2 2
CURRENT per PHASE
A
3.0 3.0 3.0 4.0 4.0 4.0 6.0 6.0 6.0
HOLDING TORQUE
N·m
0.64 1.0 1.5 0.88 1.28 2.4 4.5 8.5 12
ROTOR INERTIA
g·c m
2
180 280 520 240 490 690 1800 3600 5400
WEIGHTS
g
613 784 1231 697 862 1422 2412 3956 5486
LENGTH(L)
mm
46 55 80 47 56 85 78 117 155
PERMISSIBLE
OVERHUNG LOAD
(DISTANCE FROM
END OF SHAFT)
3mm
N
52 52 52 70 70 70 270 270 270
8mm
65 65 65 87 87 87 300 300 300
13mm
85 85 85 114 114 114 350 350 350
18mm
123 123 123 165 165 165 400 400 400
PERMISSIBLE THRUST LOAD
N
Lower than motor weight
INSULATION RESISTANCE
Mohm
100 MIN.(at 500VDC)
INSULATION CLASS
-
CLASS B(130℃)
OPERATING TEMPERATURE ℃
0 to 55
